Description
PHYSICAL
-
- Size (W x H x D) mm – Main
- 360 X 58 X 298.5
- Size (W x H x D) mm – Front Speaker
- 250x1100x250
-
- Size (W x H x D) mm – Center Speaker
- 260x93x73
- Size (W x H x D) mm – Rear Speaker
- 88x122x81
-
- Size (W x H x D) mm – Subwoofer
- 191x386x318
- Size (W x H x D) mm – Freight (20ft/40ft/40ft HC)
- 234/480/560
AMPLIFIER
-
- CH
- 5.1
- POWER OUTPUT – Total
- 1000W
-
- THD 10% – Front L/R
- 167WX2
- (3Ω:sat/3Ω:subwoofer) – Center
- 167W
-
- (3Ω:sat/3Ω:subwoofer) – Surround L/R
- 167WX2
- (3Ω:sat/3Ω:subwoofer) – Sub-Woofer
- 167W(Passive)
DESIGN(MAINSET)
-
- Uni-body (Tray)
- No
- Top & Bottom cabinet (Tray)
- No
-
- Front & Rear cabinet (tray)
- Yes
HOME MENU
-
- Cre-editable
- No
- Home Dashboard
- No
-
- Home Menu
- Yes
IN & OUT
-
- Front – Display
- FLD
- Front – USB
- 1
-
- Front – Mic – Mic In(φ6.3)
- 2
- Front – Audio In – Portable In
- Yes
CONVENIENCE
-
- Multi-tasking
- No
- Smart phone remote App
- No
-
- Magic Remote Control
- No
- SIMPLINK
- No
-
- Instant tray open – Booting Time
- No
- Warm booting
- No
-
- Booting Time
- No
- Loading Time
- No
-
- Firmware update by network
- No
- Speaker Level Trim
- Yes
-
- Speaker Distance (channel delay)
- Yes
- Test Tone
- Yes
-
- Mute
- Yes
- A/V Sync Delay(Audio Delay)
- Yes
-
- Dimmer
- Yes
- Sleep
- Yes
-
- Volume on TV
- Yes
- USB Direct Recording
- Yes
-
- External HDD Playback
- No
- TV Sound (direct key) / TV Sound connect (Auto PWR on/off by optical)
- Yes / No
-
- Dynamic Range Control – On/Off
- Yes
- Meta Data Showing GraceNote (CD/Streaming/File)
- No
-
- Progress Bar
- No
- Cinema zoom
- Yes
-
- Thumbnail – Movie/Photo
- Yes
- Wireless Speaker – 1:3 Speaker Built-in Type (Front / Subwoofer)
- No
-
- (Tx dongle Type) – 1:2 Speaker Built-in Type (Rear)
- No
- (Tx dongle Type) – 1:1 Rx module Type (Wireless Kit for rear)
- No
-
- (Tx dongle Type) – 1:1 Rx + Wireless Sub-woofer (3ch wireless)
- No
- (Tx dongle Type) – 1:1 RX for Subwoofer
- No
-
- Bluetooth (Rx / Tx)
- Yes / No
- Karaoke – Mic Volume / Echo Volume
- Yes
-
- Karaoke – Fanfare
- Yes
- Karaoke – Scoring
- Yes
-
- Karaoke – Real Time Scoring
- No
- Karaoke – Howlling Canceller
- Yes
-
- Karaoke – CD Voice Remover
- Yes
DISC & AV FORMAT
-
- Playable – BD-ROM
- No
- Disc Type – BD-R
- No
-
- Disc Type – BD-RE
- No
- Disc Type – Hybrid Disc (BD+DVD)
- No
-
- Disc Type – DVD(NTSC)
- Yes
- Disc Type – DVD(PAL)
- Yes
-
- Disc Type – DVD-R
- Yes
- Disc Type – DVD-RW(Video/VR Mode)
- Yes / No
-
- Disc Type – DVD+R
- Yes
- Disc Type – DVD+RW(Video mode)
- Yes
-
- Disc Type – DVD-RAM
- No
- Disc Type – DVD-Audio
- No
-
- Disc Type – Video CD/Super VCD
- Yes / Yes
- Disc Type – Audio CD
- Yes
-
- Disc Type – DTS-CD
- No
- Disc Type – SACD
- No
-
- Disc Type – CD-R/CD-RW
- Yes
- Video Format – MPEG2
- Yes
-
- Video Format – MPEG4 AVC (H.264)
- No
- Video Format – SMPTE VC1 (VC-9)
- No
-
- Video Format – Xvid
- Yes
- Video Format – MKV
- No
-
- Video Format – AVC Rec
- No
- Video Format – AVCHD
- No
-
- Video Format – M4V
- No
- Video Format – RMVB
- No
-
- Video Format – WMV
- No
- Video Format – FLV
- No
-
- Video Format – 3GP
- No
- Video Format – MPEG-1
- No
-
- Video Format – K3G
- No
- Video Format – MP4
- No
-
- Video Format – MOV
- No
- Video Format – VOB
- No
-
- Audio Format (Decoding) – LPCM
- LPCM
- Audio Format (Decoding) – Dolby Pro Logic II
- No
-
- Audio Format (Decoding) – Dolby Digital
- Yes
- Audio Format (Decoding) – Dolby Digital Plus
- No
-
- Audio Format (Decoding) – Dolby TrueHD
- No
- Audio Format (Decoding) – DTS
- No
-
- Audio Format (Decoding) – DTS-HD High Resolution Audio
- No
- Audio Format (Decoding) – DTS-HD Master Audio
- No
-
- Audio Format (Decoding) – DTS2.0+Digital Out
- No
- Audio Format (Decoding) – MPEG 1/2 L2
- Yes
-
- Audio Format (Decoding) – MP3 – ID3 Tag
- Yes/Yes
- Audio Format (Decoding) – FLAC
- No
-
- Audio Format (Decoding) – WMA
- Yes
- Audio Format (Decoding) – AAC
- No
-
- Graphics / Subtitle Format
- 2bit / 8bit Sub-picture
Text-based Subtitle
- Video – GUI/ Menu – Language
- Option
-
- Features – Video DAC
- 148MHZ/12bit
- Features – NTSC/PAL Hz
- 60Hz / 50Hz
-
- Features – NTSC/PAL Hz – Resolution
- upto 1080p 24 / 60Hz
- Features – VBI – WSS/CGMS-A/Closed Caption/Macrovsion
- Yes
-
- Features – NTSC⇔PAL Conversion
- Yes
- Features – HDMI 1.4
- No
-
- Features – ARC
- No
- Features – Deep Colour
- No
-
- Features – xvYCC
- No
- Features – Last Scene memory
- Yes
-
- Features – Photo Zoom
- No
- Features – Video Enhancement
- No
DISC(BD, DVD, CD)PLAYBACK SPECIFICATION
-
- General – Screen Saver
- Yes
- Auto Power Off
- Yes
-
- Parental Lock
- Yes
- Initial logo
- Yes
-
- BD – MHP-Like Interactivity
- No
- BD – Simultaneous Playback of HD & SD Video Drip
- No
-
- BD – BD ROM profile
- No
- BD – Still Picture
- No
-
- BD – Digital Cinema 4K upscaling
- No
- DVD – 1080p Upscaling
- Yes
-
- Trick Play – Fast Forward – DVD, CD-DA, MP3/WMA
- Yes
- Trick Play – Fast Back – DVD, CD-DA, MP3/WMA
- Yes
-
- Trick Play – Fast Slow – DVD
- Yes
- Trick Play – Reverse Slow
- Yes
-
- Trick Play – Pause – DVD, CD-DA, MP3/WMA
- Yes
- Trick Play – Pause – Forward Step – DVD
- Yes
-
- Trick Play – Pause – Reverse Step
- No
- Search – Title/Track – DVD, CD-DA, MP3/WMA
- Yes
-
- Search – Chapter – DVD
- Yes
- Search – Time – DVD
- Yes
-
- Repeat Play – Title/Track – HDMV, DVD, CD-DA, MP3/WMA
- Yes
- Repeat Play – Chapter – HDMV, DVD
- Yes
-
- Repeat Play – A-B – HDMV, DVD(-VR)
- No
- Resume Stop – DVD, CD-DA,MP3/WMA
- Yes
-
- Play Mode – Program – DVD, CD-DA,MP3/WMA
- No
- Play Mode – Random – CD-DA, MP3/WMA
- Yes
-
- Marker Search – 9 Points – DVD
- No
- Marker Play – CD-DA, MP3/WMA
- Yes
POWER
-
- Power – SMPS
- Option
- Power – Power Off Consumption
- 0.5W ↓
-
- Power – Power Consumption
- 145W
RADIO
-
- Tuner Type
- PLL
- Tuning Up/Down
- Yes
-
- Preset Up/Down
- Yes
- Band FM / FM(RDS) / AM
- Yes / No / No
-
- Preset Memory
- 50 Station
- RDS (PS, PTY, CT, RT)
- No
SPEAKER
-
- Including Speaker – Front – Model Name
- S67T2-S
- Including Speaker – Front – SPL
- 81dB
-
- Including Speaker – Front – System
- Closed Type
- Including Speaker – Front – Woofer Unit
- 3″ Paper
-
- Including Speaker – Front – Impedance
- 3Ω
- Including Speaker – Front – Magnetic Shielding
- Non-Shielded
-
- Including Speaker – Rear – Model Name
- S67S2-S
- Including Speaker – Rear – SPL
- 81dB
-
- Including Speaker – Rear – System
- Closed Type
- Including Speaker – Rear – Woofer Unit
- 3″ Paper
-
- Including Speaker – Rear – Impedance
- 3Ω
- Including Speaker – Rear – Magnetic Shielding
- Non-Shielded
-
- Including Speaker – Center – Model Name
- S67T2-C
- Including Speaker – Center – SPL
- 79.0dB
-
- Including Speaker – Center – System
- Closed Type
- Including Speaker – Center – Woofer Unit
- 3″ Paper
-
- Including Speaker – Center – Impedance
- 3Ω
- Including Speaker – Center – Magnetic Shielding
- Non-Shielded
-
- Including Speaker – Subwoofer – Model Name
- S67T2-W
- Including Speaker – Subwoofer – SPL
- 83dB
-
- Including Speaker – Subwoofer – System
- Bass Reflex
- Including Speaker – Subwoofer – Woofer Unit
- 7″ Paper
-
- Including Speaker – Subwoofer – Impedance
- 3Ω
- Including Speaker – Subwoofer – Magnetic Shielding
- Non-Shield
-
- Including Speaker – Rear Wireless Kit – Name
- No
FEATURE LIST & ACCESSORY KIT
-
- Instruction Manual
- Printing Book
- Instruction Manual – Simple Manual
- Yes
-
- Remote Control Unit Type
- CB1
- Remote Control Unit – MBR
- No
-
- Remote Control Unit Unified
- No
- Remote Control Unit Battery(Size)
- AAA*1
-
- Batteries (Remote Controller)
- Yes
- FM / AM Antenna
- Yes / No
-
- Speaker Cable
- Yes (5EA)
- Warranty Card
- Yes
-
- RCA Code(Audio), Red/White, 2P
- No
- RCA Code(Video), Yellow, 1P
- Yes
-
- Component Video Cable
- No
- RCA to Scart Jack Cable
- No
-
- Portable In Cable
- No
- HDMI Cable
- Yes
-
- Wireless Rx Kit
- No
- Microphone (Karaoke)
- Yes
-
- A3DSC Mic
- No
- Song Book
- No
-
- Song Disc
- No
- DLNA Set-up Disc
- No
-
- Optical Cable
- No
- Wall Mount Bracket
- No
-
- Carton Box Type – Tip on, Offset, Flexo
- Tip on
